    Globe Valve

    Globe Valve ANSI B16.10

    Size DN50—DN600Nominal Pressure PN10/PN16Working Temperature -10C~120CSuitable Medium Chemicals,air,water,steam,oil, acids,salts,etcPerformance:Nominal pressue (MPa)1.01.6Nominal diameter(mm)Shell50-6

    Quantity:
    -
    +
    SUBMIT RFQ
    Product Details



    Size DN50—DN600

    Nominal Pressure PN10/PN16

    Working Temperature -10°C~120°C

    Suitable Medium Chemicals,air,water,steam,oil, acids,salts,etc



    Performance:

    Nominal pressue (MPa)

    1.0

    1.6

    Nominal diameter(mm)

    Shell

    50-600

    50-600

    Test pressure

    Seal

    1.5

    2.4

    (MPa)

    1.1

    1.76

    Applicable temperature

    150



    Applicable medium

    Fresh water, Sewage, Sea water, Air, Vapor, Food, Medicine, Oils, Acids,
    Alkalis, etc.

    Operating mode

    manual, worm gear, pneumatic, electric, etc.



    Standards:

    Design & Manufacture

    Flange Connection

    Face to Face Dimension

    Test & Inspection

    MSS SP-70

    ANSI B16.10 (125LB)

    ANSI B16.10 (125LB)





    Material List:

    NO.

    Part Name

    Material

    1

    Body

    Cast Iron/Ductile Iron

    2

    Body Seat Ring

    Cast Bronze

    3

    Reaction Member

    Brass

    4

    Disc

    Cast Bronze

    5

    Gasket

    Brass

    6

    Swivel Nut

    Cast Brass

    7

    Boll

    Steel

    8

    Body Gasket

    Graphite

    9

    Bonnet

    Cast Iron

    10

    Packing

    Graphite

    11

    Packing Gland

    Cast Brass

    12

    Gland Follower

    Ductile Iron

    13

    Gland Follower Bolts

    Steel

    14

    Gland Follower Nuts

    Steel

    15

    Stem

    Brass

    16

    Yoke Busing

    Cast Bronze

    17

    Screw

    Steel

    18

    Handwheel

    Cast Iron

    19

    Identification

    Steel

    20

    Handwheel nut

    Ductile Iron
